Orientation and Axes

This document explains how mag-usb handles magnetometer orientation and how to configure 90° rotations around each axis.

Axis conventions

  • The RM3100 outputs three orthogonal components X, Y, Z.

  • mag-usb treats these axes as a right‑handed coordinate system.

  • Positive rotations follow the right‑hand rule (thumb points along the axis of rotation; curl of fingers is direction of positive rotation).

Why orientation adjustments?

Depending on how the sensor PCB is mounted in your enclosure, its axes may not align with your desired reference frame. mag-usb can rotate the measured vector by multiples of 90° around the X, Y, and Z axes to align with your installation.

Configuration

Set the following keys in config.toml under [mag_orientation]:

[mag_orientation]
mag_translate_x = <int>   # -180, -90, 0, 90, 180
mag_translate_y = <int>   # -180, -90, 0, 90, 180
mag_translate_z = <int>   # -180, -90, 0, 90, 180

Rules:

  • Allowed values: -180, -90, 0, 90, 180. Any other value is treated as 0.

  • 180 and -180 are treated the same (flip both perpendicular axes).

  • Rotations are applied in this order: rotate around X, then around Y, then around Z.

  • The rotations affect the other two components:

    • Rotate around X → affects Y and Z.

    • Rotate around Y → affects X and Z.

    • Rotate around Z → affects X and Y.

Examples

Let the input vector be (X, Y, Z).

  • Rotate +90° about X:

    • (X, Y, Z) → (X, -Z, Y)

  • Rotate -90° about X:

    • (X, Y, Z) → (X, Z, -Y)

  • Rotate 180° about X:

    • (X, Y, Z) → (X, -Y, -Z)

  • Rotate +90° about Y:

    • (X, Y, Z) → (Z, Y, -X)

  • Rotate -90° about Y:

    • (X, Y, Z) → (-Z, Y, X)

  • Rotate 180° about Y:

    • (X, Y, Z) → (-X, Y, -Z)

  • Rotate +90° about Z:

    • (X, Y, Z) → (-Y, X, Z)

  • Rotate -90° about Z:

    • (X, Y, Z) → (Y, -X, Z)

  • Rotate 180° about Z:

    • (X, Y, Z) → (-X, -Y, Z)

Compound rotations apply these in order X → Y → Z. For example, X=+90°, Z=-90°:

  1. X=+90°: (X, Y, Z) → (X, -Z, Y)

  2. Z=-90°: (X, -Z, Y) → (-(-Z), -X, Y) → (Z, -X, Y)

Coordinate System Fig. 7: Magnetometer orientation and axis reference.

Verification

After editing config.toml, run:

./mag-usb -P

You should see:

Orientation translate (deg XYZ): <x>, <y>, <z>

Then start normal sampling and confirm that reported axes behave as expected when you rotate the sensor in known directions.
